COMMITTED TO PROVE A SAFETY & CONVENIENT AERIAL WORKING ENVIRONMENT

MPL-AC SERIES VERTICAL LIFT

LOW PLATFORM ENTRY ALLOWS EASY STEP IN & OUT.  SINGLE ELEVATING MAST IS MADE OF ALUMINUM ALLOY WITH DUAL-CHAIN DESIGN THAT ENSURE SMOOTH AND SAFETY OPERATIONS.  AC POWERED HYDRAULIC LIFTING UNIT GIVES MOST RELIABLE PERFORMANCE.  HANDY CONTROL SWITCH ON THE PLATFORM ALLOW SINGLE PERSON OPERATION.

All TAMICO's Vertical Lift Comply With ANSI A92.3-1990 Standard & Safety Requirement

Click Here To Learn More About Product Features

@

Cat. No.

MPL-50AC

MPL-65AC

MPL-80AC

MPL-95AC

MPL-110AC

Max. Platform Height

5,000 mm

6,500 mm

8,000 mm

9,500 mm

11,000 mm

Max. Working Height

7,000 mm

8,500 mm

10,000 mm

11,500 mm

13,000 mm

Max. Load

160 kg

130 kg

Ext. Width (D)

1,400 mm

1,500 mm

1,900 mm

2,200 mm

Ext. Length (E)

1,700 mm

1,820 mm

2,265 mm

2,475 mm

Stowed Length (L)

1,200 mm

1,270 mm

1,330 mm

Stowed Width (W)

760 mm

Stowed Height (H)

1,980 mm

2,080 mm

Platform (A x B)

660 x 600 mm

Rail Height (C)

1,000 mm

Platform Entry (F)

500 mm

Power Source

110/220VB50/60HzAEQUIPPED WITH A POWER CABLE (15M)

Weights (App.)

265 kg

290 kg

315 kg

355 kg

395 kg

CONTINUOUS IMPROVEMENT IS TAMICO'S COMPANY POLICY. PRODUCT SPECIFICATIONS ARE SUBJECTED TO CHANGE WITHOUT PRIOR NOTICE. THE DRAWINGS IN THIS BROCHURE ARE FOR ILLUSTRATIVE PURPOSE ONLY.

@
